The dotAI feature offers a wealth of API tools to undertake OpenAI operations headlessly. Similar to the viewtool, the endpoints include those that focus on generation, searching, embeddings, and completions.

The various endpoints exist as child paths of /api/v1/ai, outlined below by category and path.

Generative Endpoints#

---

Generate Text (GET)#

Calling the GET text-generation endpoint requires only a prompt.

Endpoint: GET /v1/ai/text/generate

Query Parameters:

Response Type: application/json

Example:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/text/generate?prompt=test' \
  -H 'accept: application/json'

The response object resembles that of the dotAI viewtool's $ai.completions.raw() method:

{
  "id": "chatcmpl-CZJuecFUiWcPKTk9MYqJ6Qu5mBTpI",
  "object": "chat.completion",
  "created": 1762534060,
  "model": "gpt-4.1-2025-04-14",
  "choices": [
    {
      "index": 0,
      "message": {
        "role": "assistant",
        "content": "Hello! 👋 It looks like you're testing the bot. How can I assist you today with your content management needs? If you want to generate, rewrite, or review content, just let me know!",
        "refusal": null,
        "annotations": []
      },
      "logprobs": null,
      "finish_reason": "stop"
    }
  ],
  "usage": {
    "prompt_tokens": 35,
    "completion_tokens": 41,
    "total_tokens": 76,
    "prompt_tokens_details": {
      "cached_tokens": 0,
      "audio_tokens": 0
    },
    "completion_tokens_details": {
      "reasoning_tokens": 0,
      "audio_tokens": 0,
      "accepted_prediction_tokens": 0,
      "rejected_prediction_tokens": 0
    }
  },
  "service_tier": "default",
  "system_fingerprint": "fp_d38c7f4fa7"
}

Generate Text (POST)#

When called with POST, a data payload is instead required, of the type described under the section on completions forms, providing a greater range of configurability. However, the actual submissions can be as simple as only including a prompt property, as follows:

Generates text with advanced configuration options.

Endpoint: POST /v1/ai/text/generate

Request Body: CompletionsForm (application/json)

Response Type: application/json

Example Request:

curl -X 'POST' \
  'http://localhost:8082/api/v1/ai/text/generate' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{
  "prompt": "tell me about costa rica!"
  "model": "gpt-4",
  "temperature": 0.7,
  "responseLengthTokens": 256
}'

The success response object will be the same as for the corresponding GET endpoint.

For the full set of properties, see the completions form.

Generate Image (GET) (Test)#

Simple test endpoint to verify image service availability.

Endpoint: GET /v1/ai/image/test

Response Type: application/json

Success Response (200):

{
  "type": "image"
}

Generate Image (GET)#

Generates an AI image from a text prompt using query parameters.

Endpoint: GET /v1/ai/image/generate

Query Parameters:

Response Type: application/json

Error Responses:

• 400 - Missing or invalid prompt
• 401 - User not authenticated
• 500 - App config missing or internal error

Example Request:

When called with GET, only a prompt path parameter is required:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/image/generate?prompt=a%20pig%20wearing%20a%20hat' \
  -H 'accept: application/json'

The result is as follows:

{
  "revised_prompt": "A playful farm scene showcasing a pink pig. This pig is unique, it is wearing a hat possibly a sunhat for the bright sunny day. The hat is delicately perched on the pig's big head. Attention is drawn to the pig's gleeful expressions, and the curious sparkle in its eyes. Different shades of pink colour are reflected on its body indicating a healthy pig with a tinge of fun and eccentricity with the presence of the hat. The whole ambiance of the farm is of warmth and vitality. A light breeze may be rustling through making the image lively.",
  "url": "https://oaidalleapiprodscus.blob.core.windows.net/private/org-qZnNeZvyp7uFUh2EX8AJA6gw/user-2MAFKcfsfuJ7ILKoM3ZYWUcs/img-sLsWAgFW0B7U5cLaRblzmQeF.png?st=2024-02-12T13%3A29%3A31Z&se=2024-02-12T15%3A29%3A31Z&sp=r&sv=2021-08-06&sr=b&rscd=inline&rsct=image/png&skoid=6aaadede-4fb3-4698-a8f6-684d7786b067&sktid=a48cca56-e6da-484e-a814-9c849652bcb3&skt=2024-02-12T14%3A27%3A13Z&ske=2024-02-13T14%3A27%3A13Z&sks=b&skv=2021-08-06&sig=qwmBl4uETTfn14v4jQhUUUeH1HihtKm2m4udyxlmm%2BE%3D",
  "originalPrompt": "a pig wearing a hat",
  "tempFileName": "pig_20240212_022931.png",
  "response": "temp_298431dce8",
  "tempFile": "/data/shared/assets/tmp_upload/temp_298431dce8/pig_20240212_022931.png"
}

Generate Image (POST)#

Generates an AI image with advanced configuration options.

Endpoint: POST /v1/ai/image/generate

Request Body: AIImageRequestDTO (application/json)

Response Type: application/json

Example Request:

{
  "prompt": "A serene mountain landscape with a lake",
  "numberOfImages": 1,
  "size": "1024x1024",
  "quality": "hd",
  "style": "vivid"
}

See further details on the image request form data members below.

Responses are as documented under the corresponding GET method.

Search Endpoints#

---

Test Endpoint#

Simple test endpoint to verify search service availability.

Endpoint: GET /v1/ai/search/test

Response Type: application/json

Success Response (200):

{
  "type": "search"
}

Semantic Search (GET)#

Performs AI-powered semantic search using vector similarity. This endpoint accepts query parameters for basic search operations.

Endpoint: GET /v1/ai/search

Query Parameters:

When performing a GET call to ai/search, a list of query parameters are accepted that parallel the properties of the completions form used in many other functions.

Response Types:

• application/json - Complete search results
• application/octet-stream - Streaming response (when stream=true)

Success Response (200):

{
  "results": [
    {
      "identifier": "abc123",
      "title": "Matching Content Title",
      "contentType": "Blog",
      "score": 0.89,
      "content": "Relevant content excerpt..."
    }
  ],
  "totalResults": 15,
  "query": "artificial intelligence",
  "threshold": 0.5
}

Error Responses:

• 401 - User not authenticated
• 500 - Internal server error

Example Request:

Specifying a query and index should suffice as a bare minimum to yield results:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/search?query=snow&indexName=blogIndex' \
  -H 'accept: application/json'

For more refined searches with additional filtering:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/search?query=machine%20learning&searchLimit=20&contentType=Blog&threshold=0.7' \
  -H 'accept: application/json'

The returned object will have the same schema as that returned by a viewtool search function.

Semantic Search (POST)#

Performs AI-powered semantic search with form data, providing the same functionality as the GET endpoint but accepting parameters in the request body.

Endpoint: POST /v1/ai/search

Request Body: CompletionsForm (application/json)

Response Type: application/json

Example Request:

{
  "prompt": "cloud computing best practices",
  "searchLimit": 50,
  "searchOffset": 0,
  "contentType": "Blog,NewsArticle",
  "site": "demo.dotcms.com",
  "threshold": 0.6,
  "indexName": "default",
  "operator": "cosine"
}

Success Response (200):

{
  "results": [
    {
      "identifier": "xyz789",
      "title": "Cloud Computing Guide",
      "contentType": "Blog",
      "score": 0.92,
      "content": "Best practices for cloud..."
    }
  ],
  "totalResults": 23
}

Find Related Content (GET)#

Finds content semantically related to a specific piece of content using query parameters that point to the source content.

Endpoint: GET /v1/ai/search/related

Query Parameters:

Note: Either identifier or inode must be provided.

Response Type: application/json

Success Response (200):

{
  "results": [
    {
      "identifier": "related123",
      "title": "Similar Article",
      "contentType": "Blog",
      "score": 0.85,
      "content": "Related content..."
    }
  ],
  "sourceIdentifier": "abc123",
  "totalResults": 10
}

Error Responses:

• 401 - User not authenticated
• 404 - Content not found
• 500 - Internal server error

Example Request:

The five key parameters point to a piece of content (language, identifier, inode), an index (indexName), and a specific field within the contentlet (fieldVar):

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/search/related?language=0&identifier=3d6fa2a4-2b48-4421-a2f5-b6518a7c0830&inode=ae49b86b-6bd2-47d4-924e-c8e747d9bf0a&indexName=blogIndex&fieldVar=blogContent' \
  -H 'accept: application/json'

Find Related Content (POST)#

Finds related content using JSON request body, providing the same functionality as the GET endpoint but with parameters submitted as payload data.

Endpoint: POST /v1/ai/search/related

Request Body:

{
  "identifier": "abc123",
  "language": 1,
  "indexName": "default",
  "fieldVar": "body"
}

Response Type: application/json

Success Response (200):

{
  "results": [
    {
      "identifier": "related456",
      "title": "Related Content",
      "contentType": "NewsArticle",
      "score": 0.78,
      "content": "Content excerpt..."
    }
  ],
  "totalResults": 8
}

Example Request:

curl -X 'POST' \
  'http://localhost:8082/api/v1/ai/search/related' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{
  "language":0,
  "identifier":"3d6fa2a4-2b48-4421-a2f5-b6518a7c0830",
  "inode":"ae49b86b-6bd2-47d4-924e-c8e747d9bf0a",
  "indexName":"blogIndex",
  "fieldVar":"blogContent"
}'

Embeddings Endpoints#

---

Test Endpoint#

Simple test endpoint to verify embeddings service availability.

Endpoint: GET /v1/ai/embeddings/test

Response Type: application/json

Success Response (200):

{
  "type": "embeddings"
}

Create Embeddings#

Creates vector embeddings for content matching the provided query. Processes content in batches and adds them to the specified index.

Endpoint: POST /v1/ai/embeddings

Request Body: EmbeddingsForm (application/json)

Response Type: application/json

Success Response (200):

{
  "timeToEmbeddings": "5432ms",
  "totalToEmbed": 150,
  "indexName": "default"
}

Error Responses:

• 401 - User not authenticated
• 500 - Internal server error with error details

Example Request:

curl -X 'POST' \
  'http://localhost:8082/api/v1/ai/embeddings' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{
  "query": "+contentType:blogIndex +variant:default +live:true",
  "limit": 1000,
  "offset": 0,
  "indexName": "blogIndex",
  "model": "text-embedding-ada-002",
  "fields":"blogContent"
}'

Notes:

• Processes up to 10,000 iterations
• Automatically adds +live:true to query
• Results sorted by modification date
• Batch processes based on limit parameter

Delete Embeddings#

Deletes embeddings matching specific criteria or by query. Can delete individual contentlets, entire content types, or arbitrary query results.

Endpoint: DELETE /v1/ai/embeddings

Request Body (Option 1 - Query-based deletion):

{
  "deleteQuery": "+contentType:Blog +site:demo.dotcms.com",
  "indexName": "default"
}

Request Body (Option 2 - Specific deletion):

{
  "indexName": "default",
  "identifier": "abc123",
  "language": 1,
  "inode": "def456",
  "contentType": "Blog",
  "site": "demo.dotcms.com"
}

Response Type: application/json

Success Response (200):

{
  "deleted": 42
}

Error Responses:

• 401 - User not authenticated
• 500 - Internal server error

Example Request:

curl -X 'DELETE' \
  'http://localhost:8082/api/v1/ai/embeddings' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{
  "indexName": "blogIndex",
  "contentType": "Blog"
}'

Count Embeddings (GET)#

Counts embeddings matching filter criteria using query parameters.

Endpoint: GET /v1/ai/embeddings/count

Query Parameters:

Response Type: application/json

Success Response (200):

{
  "embeddingsCount": 1543
}

Example Request:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/embeddings/count?contentType=Blog&site=demo.dotcms.com&indexName=default' \
  -H 'accept: application/json'

Count Embeddings (POST)#

Counts embeddings matching filter criteria using form data.

Endpoint: POST /v1/ai/embeddings/count

Request Body: CompletionsForm (application/json)

Response Type: application/json

Success Response (200):

{
  "embeddingsCount": 892
}

Example Request:

{
  "contentType": "Blog",
  "site": "demo.dotcms.com",
  "indexName": "default",
  "language": "1",
  "prompt": "NOT USED"
}

Count Embeddings by Index#

Returns count of embeddings grouped by index name with detailed statistics. Requires CMS Administrator role.

Endpoint: GET /v1/ai/embeddings/indexCount

Required Role: CMS_ADMINISTRATOR_ROLE

Response Type: application/json

Success Response (200):

{
  "indexCount": {
    "blogIndex": {
      "contentTypes": "Activity,Blog,calendarEvent,Image,webPageContent",
      "contents": 42,
      "fragments": 91,
      "tokenTotal": 26797,
      "tokensPerChunk": 294
    },
    "products": {
      "contentTypes": "Product",
      "contents": 892,
      "fragments": 1523,
      "tokenTotal": 45231,
      "tokensPerChunk": 312
    },
    "cache": {
      "contentTypes": "cache",
      "contents": 1,
      "fragments": 80,
      "tokenTotal": 21579,
      "tokensPerChunk": 269
    }
  }
}

Error Responses:

• 401 - User not authenticated
• 403 - Insufficient permissions
• 500 - Internal server error

Example Request:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/embeddings/indexCount' \
  -H 'accept: application/json'

Drop and Recreate Embeddings Table#

⚠️ DESTRUCTIVE OPERATION - Drops and recreates the entire embeddings table. Requires CMS Administrator role. Use with extreme care.

Endpoint: DELETE /v1/ai/embeddings/db

Required Role: CMS_ADMINISTRATOR_ROLE

Request Body: {} (empty JSON object)

Response Type: application/json

Success Response (200):

{
  "created": true
}

Error Responses:

• 401 - User not authenticated
• 403 - Insufficient permissions (not CMS Administrator)
• 500 - Internal server error

Example Request:

curl -X 'DELETE' \
  'http://localhost:8082/api/v1/ai/embeddings/db' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{}'

Completions Endpoints#

---

Generate AI Completions from Content#

Generates AI-powered summaries and completions based on provided prompts with content preprocessing. This endpoint searches for relevant content and uses it to generate contextually-aware responses.

Endpoint: POST /v1/ai/completions

Request Body: CompletionsForm (application/json)

Response Types:

• application/json - Complete response with all metadata
• application/octet-stream - Streaming response (when stream: true)

Success Response (200 - JSON):

{
  "response": "Generated completion text...",
  "model": "gpt-4",
  "tokens": 150,
  "totalTime": "1250ms"
}

Success Response (200 - Streaming):

When application/octet-stream is used (typically when stream: true), the response is delivered as a line-by-line text stream. Each chunk of generated text is sent immediately as it becomes available, rather than waiting for the complete response.

Error Responses:

• 400 - Missing or invalid prompt
• 401 - User not authenticated
• 500 - Internal server error

Example Request:

curl -X 'POST' \
  'http://localhost:8082/api/v1/ai/completions' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{
  "prompt": "where do i vacation?",
  "threshold": ".2",
  "searchLimit": 50,
  "stream": false,
  "indexName": "blogIndex"
}'

The endpoint returns detailed completion data containing the prompt response along with the relevant content matches:

{
  "timeToEmbeddings": "860ms",
  "total": 5,
  "query": "What's the best place to vacation?",
  "threshold": 0.25,
  "dotCMSResults": [
    {
      "identifier": "abc123",
      "matches": [
        {
          "distance": 0.21085739135742188,
          "extractedText": "<text excerpt>..."
        }
      ]
    }
  ],
  "operator": "<=>",
  "offset": 0,
  "limit": 50,
  "count": 3,
  "openAiResponse": {
    "id": "chatcmpl-8rUy56hdxj210olTgFbNfVpxKVQla",
    "object": "chat.completion",
    "created": 1707761117,
    "model": "gpt-3.5-turbo-16k-0613",
    "choices": [
      {
        "index": 0,
        "message": {
          "role": "assistant",
          "content": "Based on the information provided, Fiji would be an excellent destination for a vacation. Fiji is located in the heart of the South Pacific and is blessed with 333 tropical islands. The islands are known for their luxurious..."
        },
        "logprobs": null,
        "finish_reason": "stop"
      }
    ],
    "usage": {
      "prompt_tokens": 325,
      "completion_tokens": 139,
      "total_tokens": 464
    },
    "system_fingerprint": null
  },
  "totalTime": "2475ms"
}

Get AI Configuration#

Retrieves current AI service configuration including available models, settings, and prompts. This endpoint returns the configuration values visible in the Config Values tab in the dotAI Tool.

Endpoint: GET /v1/ai/completions/config

Response Type: application/json

Success Response (200):

{
  "configHost": "demo.dotcms.com (falls back to system host)",
  "apiUrl": "https://api.openai.com/v1",
  "apiKey": "*****",
  "model": "gpt-4",
  "embeddingsModel": "text-embedding-ada-002",
  "rolePrompt": "You are a helpful assistant...",
  "availableModels": [
    {
      "name": "gpt-4",
      "type": "chat",
      "maxTokens": 8192
    },
    {
      "name": "gpt-3.5-turbo",
      "type": "chat",
      "maxTokens": 4096
    }
  ]
}

Error Responses:

• 401 - User not authenticated
• 500 - Internal server error

Example Request:

curl -X 'GET' \
  'http://localhost:8082/api/v1/ai/completions/config' \
  -H 'accept: application/json'

A typical returned object will resemble this:

{
  "apiImageUrl": "https://api.openai.com/v1/images/generations",
  "apiKey": "*****",
  "apiUrl": "https://api.openai.com/v1/chat/completions",
  "availableModels": [
    "gpt-3.5-turbo",
    "gpt-3.5-turbo-16k",
    "gpt-4",
    "gpt-4-1106-preview"
  ],
  "com.dotcms.ai.completion.default.temperature": "1",
  "com.dotcms.ai.completion.model": "gpt-3.5-turbo-16k",
  "com.dotcms.ai.completion.role.prompt": "You are a helpful assistant with a descriptive writing style.",
  "com.dotcms.ai.completion.text.prompt": "Answer this question\\n\\\"$!{prompt}?\\\"\\n\\nby using only the information in the following text:\\n\"\"\"\\n$!{supportingContent} \\n\"\"\"\\n",
  "com.dotcms.ai.debug.logging": "false",
  "com.dotcms.ai.embeddings.build.for.file.extensions": "pdf,doc,docx,txt,html",
  "com.dotcms.ai.embeddings.cache.size": "1000",
  "com.dotcms.ai.embeddings.cache.ttl.seconds": "600",
  "com.dotcms.ai.embeddings.delete.old.on.update": "true",
  "com.dotcms.ai.embeddings.minimum.file.size": "1024",
  "com.dotcms.ai.embeddings.minimum.text.length": "64",
  "com.dotcms.ai.embeddings.model": "text-embedding-ada-002",
  "com.dotcms.ai.embeddings.search.default.threshold": ".25",
  "com.dotcms.ai.embeddings.split.at.tokens": "512",
  "com.dotcms.ai.embeddings.threads": "3",
  "com.dotcms.ai.embeddings.threads.max": "6",
  "com.dotcms.ai.embeddings.threads.queue": "10000",
  "configHost": "demo.dotcms.com (falls back to system host)",
  "imageModel": "dall-e-3",
  "imagePrompt": "Use 3:4 aspect ratio.",
  "imageSize": "1792x1024",
  "listenerIndexer": "{\n    \"blogIndex\":\"Blog.blogContent\"\n}",
  "model": "gpt-3.5-turbo-16k",
  "rolePrompt": "You are dotCMSbot, and AI assistant to help content creators generate and rewrite content in their content management system.",
  "textPrompt": "Use Descriptive writing style."
}

Common Data Models#

---

CompletionsForm#

Used for completions, search, and text generation requests.

Fields:

Example:

{
  "prompt": "Analyze customer feedback trends",
  "searchLimit": 100,
  "contentType": "Review,Comment",
  "temperature": 0.5,
  "model": "gpt-4",
  "threshold": 0.7,
  "stream": false,
  "responseLengthTokens": 512
}

EmbeddingsForm#

Used for creating and managing embeddings.

Fields:

Example:

{
  "query": "+contentType:Blog +live:true",
  "limit": 500,
  "offset": 0,
  "indexName": "default",
  "model": "text-embedding-ada-002",
  "fields": "title,body,tags"
}

AIImageRequestDTO#

Used for image generation requests.

Fields:

Example:

{
  "prompt": "A peaceful garden with cherry blossoms",
  "numberOfImages": 1,
  "size": "1024x1024",
  "quality": "hd",
  "style": "vivid"
}
